Many liquid products—such as foodstuffs, oils, and chemicals,
tend to thicken or even solidify during transportation or storage, making them difficult to discharge from IBCs.
LAF Electric Heating Pad offers a highly efficient heating solution that simplifies unloading, improves safety, and reduces costs.
Installed beneath the liner bag prior to filling, the pad gradually heats the product at the destination,
ensuring smooth discharge without additional equipment or facilities.
Key Features & Benefits
Easy to operate: Direct heating enables efficient and smooth unloading.
High Heating Efficiency: Increased heating wire density improves the heating speed.
Uniform Heating: Laminated foil structure ensures even heat distribution across the product base.
Bi-metal Thermostat System: Equipped with an advanced 55/65°C bi-metal limiter, offers double-layered safety protection.
Safe & Reliable: Over-temperature protection and silicone insulation prevent liner damage.
Cost Saving: Reduces the need for hot rooms or water baths; lowers unloading costs and labor.
Heating Element: Silicone rubber-insulated cable with resistance wire cores
Layering: Kraft paper and aluminum foil laminated structure for optimal heat transfer
Bi-metal Thermostat System: 55/65°C bi-metal limiter
Plug Type: International universal plug & US, AU, UK, EU and other regional plug
For unloading viscous or easily solidifying liquids, the heating pad can be activated when solidification occurs.
It assists in raising the temperature to maintain the material in a liquid state,
preventing pipeline blockages and resolving potential loading or unloading difficulties caused by solidification, such as:
Foodstuffs, Chemicals, Milk fat products, Vegetable oils and fats, Pharmaceutical ingredients
Collapsible Paper IBC
Collapsible Plastic IBC
Collapsible Metal IBC
IBC Foil Heaters Specification
| Item | Technical Data |
Voltag | 220V or 110V |
Output Power | 1100W |
| Bi-metal Thermostat | 55/65°C |
| Layout Dimension | 960mmx870mm |
Power Cable | 1.8m power cable |
Why Choose LAF IBC Aluminum Foil Heater?
✔ Easy installation, no special tools required
✔ Speeds up discharge time significantly
✔ Reduces carbon footprint by eliminating the need for heated warehouses
✔ Enhances safety and ensures product integrity
